| Item | Part No. | Description | VDD | Operating current | OP AMP (stage) | LDO | Delay Time | CDS Detect | PMO | Dimming ON/OFF | Output | |
| CMOS/ open Drain PWM | Active High/ Low | |||||||||||
| 1 | PIR Controller IC for LED Lamp | 3.6 ~ 5.5V | 20uA @4.5V | 2 | Y | 3 ~ 220sec | Y | N | N | pin option | pin option | |
| 2 | PIR sensor control chip | 2.7 ~ 5.5V | 40uA @5.0V | 2 | Y | 3sec ~ 15min/ 6sec ~ 30min | Y | Y | Y | CMOS | Low | |
| 3 | PIR sensor control chip | 1.8 ~ 6V | 50uA @3.0V | 2 | N | TX ≈ 49152R1C | Y | N | N | CMOS | High | |
| 4 | TTR011+TTY020 PIR Controller | 2.4 ~ 5.0V | | 2 | N | - | - | - | - | | | |
| 5 | PIR sensor control chip | 2.7~ 5.5V | 50uA @5.0V | 2 | N | - | Y | Y | N | Triac | Low Pulse | |
| Relay | High | |||||||||||
| Item | Part No. | Description | VDD | Operating current | LVD | OSC | LCD Seg/Com | LCD bias, duty | Temperature range | Resolution | Accuracy | Sensor | ||
| 1 | Electronic Clinical Thermometer IC | 1.25 ~ 1.65V | 30 uA | TT5660A | 1.30 ± 0.05V | External R 32KHz | 13 x 3 | 1/2, 1/3 | 32℃ ~ 42℃ / 89.6℉ ~ 107.6℉32℃ ~ 44℃ / 89.6℉ ~ 111.2℉ | 0.1℃/ 0.1℉ | ± 0.1℃/ ± 0.2℉ | ET-503 | ||
| TT5660B | 1.35 ± 0.05V | |||||||||||||
| 2 | Electronic Clinical Thermometer IC | 1.3 ~ 1.60V | 30 uA | 1.35 ± 0.05V | External R 32KHz | 13 x 3 | 1/2, 1/3 | 32℃ ~ 43℃ / 89.6℉ ~ 109.4℉ | 0.01℃/ 0.01℉ | ± 0.1℃/ ± 0.2℉ | ET-503 | |||
| 3 | Electronic Clinical Thermometer IC | 1.25 ~ 1.65V | 50 uA | 1.35 ± 0.05V Adjustable | External R 32KHz | 10 x 3 | 1/2, 1/3 | 32℃ ~ 42.9℃ / 89.6℉ ~ 109.9℉ | 0.1℃/ 0.1℉ | ± 0.1℃/ ± 0.2℉ | ET-503 | |||
| 4 | Electronic Clinical Thermometer IC | 1.25 ~ 1.65V | 50 uA | TTP301A | 1.30 ± 0.05V | External R 32KHz | 10 x 3 | 1/2, 1/3 | 32℃ ~ 42.9℃ / 89.6℉ ~ 109.9℉ | 0.1℃/ 0.1℉ | ± 0.1℃/ ± 0.2℉ | ET-503 | ||
| TTP301B | 1.35 ± 0.05V | |||||||||||||
| 5 | Electronic Clinical Thermometer IC | 1.2 ~ 1.65V | 50 uA | TTP310A | 1.30 ± 0.05V | External R 32KHz | 10 x 3 | 1/2, 1/3 | 32℃ ~ 42.9℃ / 89.6℉ ~ 109.9℉ | 0.1℃/ 0.1℉ | ± 0.1℃/ ± 0.2℉ | ET-503 | ||
| TTP310B | 1.25 ± 0.05V | |||||||||||||
| 6 | Electronic Clinical Thermometer IC | 1.3 ~ 1.6V | 30 uA | 1.30 ± 0.05V | External R 32KHz | 10 x 3 | 1/2, 1/3 | 32℃ ~ 42.9℃ / 89.6℉ ~ 109.9℉ | 0.01℃/ 0.01℉ or 0.1℃/ 0.1℉ | ± 0.1℃/ ± 0.2℉or ± 0.01℃/ ± 0.02℉ | ET-503 | |||
